Resolution: 1%
Accuracy: 0.1%(0%~1%) ; 1%(1%~20%); >20%no definition.
Power Requirements: Two AAA alkaline Batteries
Power consumption: 30mA(Normal)
Low battery indication:When the battery voltage is 1.9V±0.2V, the oximeter will automatically shut down
Battery Life: Two AAA 1.5V, 600mAh alkaline batteries could be continuously operated as long as 24 hours.
Dimension: LengthxWidthxHeight: 6.3*3.6*3.3cm
Weight: 38.1 g (without battery)
Environment Requirements:
Temperature: 10℃- 40℃
Humidity (non-condensing): 15%-95%
Atmospheric pressure : 70 kPa-106 kPa
Storage/transportation conditions
Temperature: -20℃- 50℃
Humidity (non-condensing): 10%-95%
Atmospheric pressure: 70 kPa-106 kPa
Measurement Performance in Low Perfusion Condition:0.3%.
Safety Classification
Type of protection against electric shock:
Internally powered equipment)
Degree of protection against electric shock:
Type BF-Applied part (non-defibrillation proof)
Operating mode: Continuous operation
Degree of protection against hazards of explosion: IP22
Range of the peak wavelengths: RED: 660nm/IR: 905nm
Maximum optical output power: 1.2mW
Use-life: Two years
unit size &weight: 6.3*3.6*3.3cm; N/W: 43g
GB size:95×63×43cm
carton size&weight:120 units, 40*35*29CM;
G/W: 11.5KG N/W:10.5
70B
